i-Logic Basics

Quick Information

Call

01905 458000

Course Length: 1 day

Cost: £250

Course Details:

Enquire

Inventor i-logic is core to Inventor 2011 and is about driving the dimensions, equations, attributes, features, components, properties and every other aspect of your design in Inventor using simple logical expressions. This course is designed to introduce delegates with the operational features of the ilogic Module within Autodesk Inventor and is intended for designers and engineers with little or no programming expertise.

Start Time: 9.30 am
Coffee Break: 11.00 - 11.15am
Lunch: 1.00 - 2.00pm
Coffee Break: 3.00 - 3.15pm
Finish: 5.15pm



Course Outline

  • ilogic concepts and terminology.
  • The ilogic interface.
  • Creating parameters.
  • That's a key parameter.
  • Creating multi-value parameters.
  • Creating your first rule.
  • Understanding rules based design.
  • Driving the model through rules.
  • Controlling features and dimensions.
  • Linking to Excel.
  • Push and pull from Excel.
  • Driving assemblies with ilogic.
  • Replacing assembly components.
  • Controlling drawings.
  • Changing iproperties.
  • Triggers for rules.
  • Dos and don'ts.

Audience

Users of Inventor who wish to extend their knowledge of the ilogic features of AutoCAD Inventor
